ALMCO Sutton Large Part Finishing

Heavy-duty spindle finishing for turbine disks, blades, blisks, and impellers

Models
CFT-2000 to CFT-6000
Spindle Speed
30 to 1200 RPM
Max Part Diameter
18 to 55 in
Drive
30 to 125 HP
Request a Quote

CFT Series

The Sutton Centri-Flo Tornado does the work through the spindle. The part rotates at high speed and at varied angles in a tub of vibrating media, and the spindle can sit at angles, swing through the media like a pendulum, and stop mid-cycle to reverse direction. That motion flows media and liquid through the part's features to deburr edges and blend surfaces on turbine disks, blades, blisks, and impellers.

CFT Series

Range

Models
CFT-2000 to CFT-6000
Spindle Speed
30 to 1200 RPM
Max Part Diameter
18 to 55 in
Drive
30 to 125 HP

Model Lineup

CFT-2000
200-1200 RPM, 18 in max part, 30 HP, 65 x 90 x 108 in
CFT-2500
125-750 RPM, 30 in max part, 30 HP, 75 x 112 x 90 in
CFT-3000
125-750 RPM, 40 in max part, 50 HP, 105 x 135 x 90 in
CFT-4000
125-750 RPM, 40 in max part, 75 HP, 105 x 135 x 108 in
CFT-6000
30-250 RPM, 55 in max part, 125 HP, 120 x 190 x 142 in

Motion & Controls

Tub
Vibrates, no rotation
Spindle
Rotates at varied angles and directions
Positioning
Stationary or oscillating
Controls
PLC touchscreen
Standard
Auto lubrication, flowmeter, interlocking doors

CF Series

One of the three Sutton Centri-Flo large part finishing machines, distinguished from the CFT and CFCA by how the tub and spindle move. Like the rest of the Sutton line, it is a heavy-duty spindle finisher built for high-production deburring and surface blending on turbine disks, blades, blisks, and impellers. Detailed model specifications are not published in the current spec sheet, so the values below are marked for verification.

CF Series

Overview

Type
Sutton Centri-Flo large part spindle finishing
Best For
Turbine disks, blades, blisks, impellers
Spindle Speed
TODO: verify
Max Part Diameter
TODO: verify
Drive
TODO: verify
Overall Dimensions
TODO: verify

CFCA Series

One of the three Sutton Centri-Flo large part finishing machines, distinguished from the CF and CFT by how the tub and spindle move. It shares the Sutton mission of high-production deburring and surface blending on turbine disks, blades, blisks, and impellers. Detailed model specifications are not published in the current spec sheet, so the values below are marked for verification.

CFCA Series

Overview

Type
Sutton Centri-Flo large part spindle finishing
Best For
Turbine disks, blades, blisks, impellers
Spindle Speed
TODO: verify
Max Part Diameter
TODO: verify
Drive
TODO: verify
Overall Dimensions
TODO: verify

Features

Built In

  • The spindle does the work, swinging and rotating the part through vibrating media so the media flows through every feature to deburr edges and blend surfaces.
  • Spindles position at angles, oscillate like a pendulum, and reverse mid-cycle, which reaches the complex geometry of disks, blades, blisks, and impellers.
  • PLC touchscreen control, automatic lubrication, a flowmeter, and interlocking safety doors come standard on the CFT.
  • Options add a compound dispensing system, hour meter, operator work platform, and tooling for your specific parts.

Applications

Where It Works

  • Turbine disks and blisks
  • Blades and impellers
  • Aerospace and power generation parts
  • High-production large-part deburring
